DO YOU NEED
PERMIT-READY PLANS?

(BY VIRTUACTIVE'S STANDARDS)

VirtuActive's Standards:
Full floor plans and elevation views
All structure is sized and dimensions are placed on plans.

YES

Please click here to view our
B.A.R. information and pricing

NO

Please click here to view our
B.A.R. Lite information and pricing



BASEMENTS, ADDITIONS & REMODELS

Our team meets you on-site at your remodel, addition or basement project to go over wants and needs before finishing the plans. We can work with anyone to create a

new design with 3D visuals and a complete set of working drawings to be

used for bidding, permitting & construction.

CONSUMER PRICING:

$1.50/square foot altered

$0.75/square foot below grade

$0.30/square foot unaltered

INDUSTRY PROFESSIONAL PRICING:

$1.30/square foot altered

$0.65/square foot below grade

$0.30/square foot unaltered

ALTERED SQUARE FOOT:

Any part of the finished square footage within a project that is changing.

UNALTERED SQUARE FOOT:

Any part of the project that has to be redrawn for the purposes of plan accuracy but changes are not taking place within the square footage.

WHAT'S INCLUDED:
  • Full Working Drawings in PDF form

  • 5-10 Photo Realistic 3D Renders (any BAR project under 1,500 altered sqft)

  • 10-20 Photo Realistic 3D Renders (any BAR project over 1,500 altered sqft)

Please Note: The photos will be determined by the Designer or Drafter responsible for the project and may not include every room in the home. If there are specific rooms that you want to request, please notify

your Designer/Drafter. For an expanded 3D Visual Package, that includes all rooms in a home,

please refer to our 3D Premium Package or consult with your Designer/Drafter

about using the allotted 1 hours modification time.

Time, efficiency and budget.
They are important to your project. It should be the same principles with your design.
1
Initial Site Visit
Every project should be unique and reflect your vision. For most projects we will come to your remodel project to gather information on your wants and needs such as square footage and style. No existing floor plan? No problem! We will measure up the space while we're on site.
How should I prepare?
Do you have an existing floorplan?
Existing utilities
located
Clear access to all areas to be altered
Ideas in mind of the desired changes
bigstock-Schedule-Your-Free-Consultation
Beneficial to have remodel contractor on site (if available)
What if I already have the floorplan? Do you still need to come on site?
Not always but it's still recommended so we can get a feel for the space, structure, utilties etc.
2
Redraw
Once we complete the site measure, we will then start by redrawing your space. This way we have specific dimensions before starting any changes.
3
Redesign
After the existing space has been drawn, the next step is to overlay the new design. Your 3D project will be emailed to you showing the updated floor plans as well as 3D views throughout.

press to zoom

press to zoom

press to zoom

press to zoom
1/10
4
Working Drawings
The construction documents or Working Drawings are the final phase of the process. This is the set of plans that will be used to build the project and be given to your builder, subcontractors, suppliers etc. (note that not all views below may be included on every project depending on the size and scale)
Cover Page
page 1.JPG
Existing Floor Plan
page 5.JPG
Existing Elevation
page 2.JPG
Existing Foundation Plan
page 6.JPG
New Elevation
page 3.JPG
New Floor Plan
page 7.JPG
3D Exterior Views
page 4.JPG
Electrical  Plan
page 8.JPG
5
3D Visual Package
A typical 3D Visual Package will consist of 3D renders and videos. These can be used for marketing purposes, for your contractor or for personal use.
Denali - Jensen 1.jpg
Denali - Jensen 0.jpg
Denali - Jensen 8.jpg
Denali - Jensen 2.jpg


B.A.R. LITE

Our 3D visual product which allows you to "remodel" your home so you can

see what your new space look like. This product also includes a basic floor plan

layout of your new "remodel."

CONSUMER PRICING:

$1.20/square foot altered

$0.75/square foot below grade

$0.30/square foot unaltered

INDUSTRY PROFESSIONAL PRICING:

$1.00/square foot altered

$0.65/square foot below grade

$0.30/square foot unaltered

ALTERED SQUARE FOOT:

Any part of the finished square footage within a project that is changing.

UNALTERED SQUARE FOOT:

Any part of the project that has to be redrawn for the purposes of plan accuracy but changes are not taking place within the square footage.

WHAT'S INCLUDED:
  • Basic Floor Plan Layout

  • 5-10 Photo Realistic 3D Renders (any BAR project under 1,500 altered sqft)

  • 10-20 Photo Realistic 3D Renders (any BAR project over 1,500 altered sqft)

Please Note: The photos will be determined by the Designer or Drafter responsible for the project and may not include every room in the home. If there are specific rooms that you want to request, please notify

your Designer/Drafter. For an expanded 3D Visual Package, that includes all rooms in a home,

please refer to our 3D Premium Package or consult with your Designer/Drafter

about using the allotted 1 hours modification time.

What We Need:

Our B.A.R. Lite product does not include a site visit. To be as specific as possible, we ask our

clients to provide some information prior to beginning the project.

The final rooms and dimensions will be dimensioned and detailed to the best of VirtuActive's

ability based off the details provided by the client, but cannot be guaranteed.

We ask our clients to provide as many photos as possible of the current space

and a plan with basic dimensions.

Existing plans of the space are preferred but hand drawn sketches with

basic dimensions are accepted also.

Example of Hand Drawn Sketch:

Example of a Plan with Basic Dimensions:

Screen Shot 2021-08-30 at 11.11.55 AM.png
Screen Shot 2021-08-13 at 4.06.42 PM.png

Example of Photos:

IMG_0239.HEIC
IMG_0232.HEIC
1
Redraw of Current Space
Your drafter will redraw your current space in our software which allows us to be able to make changes to create the new space.
2
New Design & Basic 3D Screenshots
Your drafter will create the new design based off the redraw. You will receive basic 3D screenshots of the design to approve before moving forward to the final plans.
3
Final Floor Plans (not permit ready) and 3D Visual Package
After approval of the design, your drafter will finalize the plans (which are not permit ready to VirtuActive's standards) and the 3D Visual Package.

Final Basic Floor Plan Example:

Screen Shot 2021-09-13 at 2.46.07 PM.png

Final Renders
Example:
